Mechanical Properties

Mechanical Properties

Alloy No.	Temper condition	Code	Tensile Test			Bending Test			Hardness Test
			Thickness (mm)	Tensile Strength (N/mm²)	Extruding Rate(%)	Thickness (mm)	Bending Angle	Inner Radius	Thickness (mm)	Vickers Hardness(HV)
C2100	O	C2100.P-O	over0.3~under30	over 205	over 33	under 2	180	contact	-	-
		C2100.R-O	over0.3~under3
	1/4H	C2100.P-1/4H	over0.3~under30	225~305	over 23	under 2	180	thickness x 0.5	-	-
		C2100.R-1/4H	over0.3~under3
	1/2H	C2100.P-1/2H	over0.3~under20	265~345	over 18	under 2	180	thickness x 1	-	-
		C2100.R-1/2H	over0.3~under3
	H	C2100.P-H	over0.3~under10	over 305	-	under 2	180	thickness x 1.5	-	-
		C2100.R-H	over0.3~under3

Alloy No.	Temper condition	Code	Tensile Test			Bending Test			Hardness Test
			Thickness (mm)	Tensile Strength (N/mm²)	Extruding Rate(%)	Thickness (mm)	Bending Angle	Inner Radius	Thickness (mm)	Vickers Hardness(HV)
C2200	O	C2200.P-O	over0.3~under30	over 225	over 35	under 2	180	contact	-	-
		C2200.R-O	over0.3~under3
	1/4H	C2200.P-1/4H	over0.3~under30	255~335	over 25	under 2	180	thickness x 0.5	-	-
		C2200.R-1/4H	over0.3~under3
	1/2H	C2200.P-1/2H	over0.3~under20	285~365	over 20	under 2	180	thickness x 1	-	-
		C2200.R-1/2H	over0.3~under3
	H	C2200.P-H	over0.3~under10	over 335	-	under 2	180	thickness x 1.5	-	-
		C2200.R-H	over0.3~under3

Alloy No.	Temper condition	Code	Tensile Test			Bending Test			Hardness Test
			Thickness (mm)	Tensile Strength (N/mm²)	Extruding Rate(%)	Thickness (mm)	Bending Angle	Inner Radius	Thickness (mm)	Vickers Hardness(HV)
C2300	O	C2300.P-O	over0.3~under30	over 245	over 40	under 2	180	contact	-	-
		C2300.R-O	over0.3~under3
	1/4H	C2300.P-1/4H	over0.3~under30	275~355	over 28	under 2	180	thickness x 0.5	-	-
		C2300.R-1/4H	over0.3~under3
	1/2H	C2300.P-1/2H	over0.3~under20	305~380	over 23	under 2	180	thickness x 1	-	-
		C2300.R-1/2H	over0.3~under3
	H	C2300.P-H	over0.3~under10	over 335	-	under 2	180	thickness x 1.5	-	-
		C2300.R-H	over0.3~under3

Alloy No.	Temper condition	Code	Tensile Test			Bending Test			Hardness Test
			Thickness (mm)	Tensile Strength (N/mm²)	Extruding Rate(%)	Thickness (mm)	Bending Angle	Inner Radius	Thickness (mm)	Vickers Hardness(HV)
C2400	O	C2400.P-O	over0.3~under30	over 255	over 44	under 2	180	contact	-	-
		C2400.R-O	over0.3~under3
	1/4H	C2400.P-1/4H	over0.3~under30	295~375	over 30	under 2	180	thickness x 0.5	-	-
		C2400.R-1/4H	over0.3~under3
	1/2H	C2400.P-1/2H	over0.3~under20	325~400	over 25	under 2	180	thickness x 1	-	-
		C2400.R-1/2H	over0.3~under3
	H	C2400.P-H	over0.3~under10	over 375	-	under 2	180	thickness x 1.5	-	-
		C2400.R-H	over0.3~under3

Alloy No.	Temper condition	Code	Tensile Test			Bending Test			Hardness Test
			Thickness(mm)	Tensile Strength (N/mm²)	Extruding Rate(%)	Thickness (mm)	Bending Angle	Inner Radius	Thickness (mm)	Vickers Hardness (HV)
C2600	O	C2600P-O	over0.3~under1	over 275	over 40	under 2	180	contact	over 0.3	-
			excess1~under30	over 275	over 50
		C2600R-O	over0.3~under3	over 275	over 40
			excess1~under3	over 275	over 50
	1/4H	C2600P-1/4H	over0.3~under30	325~410	over 35	under 2	180	thickness x 0.5	over 0.3	75~125
		C2600R-1/4H	over0.3~under3
	1/2H	C2600P-1/2H	over0.3~under20	355~440	over 28	under 2	180	thickness x 1	over 0.3	85~145
		C2600R-1/2H	over0.3~under3
	H	C2600P-H	over0.3~under10	410~540	-	under 2	180	thickness x 1.5	over 0.3	105~175
		C2600R-H	over0.3~under3
	EH	C2600P-EH	over0.3~under10	over 520	-	under 2	180	-	over 0.3	over 145
		C2600R-EH	over0.3~under3

Alloy No.	Temper condition	Code	Tensile Test			Bending Test			Hardness Test
			Thickness(mm)	Tensile Strength (N/mm²)	Extruding Rate(%)	Thickness (mm)	Bending Angle	Inner Radius	Thickness (mm)	Vickers Hardness (HV)
C2680	O	C2680 P-O	over0.3~under1	over 275	over 40	under 2	180	contact	-	-
			excess1~under30	over 275	over 50
		C2680 R-O	over0.3~under1	over 275	over 40
			excess1~under3	over 275	over 50
	1/4H	C2680 P-1/4H	over0.3~under30	325~410	over 35	under 2	180	thickness x 0.5	-	75~125
		C2680 R-1/4H	over0.3~under3
	1/2H	C2680 P-1/2H	over0.3~under20	355~440	over 28	under 2	180	thickness x 1	over 0.3	85~145
		C2680 R-1/2H	over0.3~under3
	H	C2680 P-H	over0.3~under10	410~540	-	under 2	180	thickness x 1.5	over 0.3	105~175
		C2680 R-H	over0.3~under3
	EH	C2680 P-EH	over0.3~under10	over 520	-	under 2	180	-	over 0.3	over 145
		C2680 R-EH	over0.3~under3

Alloy No.	Temper condition	Code	Tensile Test			Bending Test			Hardness Test
			Thickness (mm)	Tensile Strength (N/mm²)	Extruding Rate(%)	Thickness (mm)	Bending Angle	Inner Radius	Thickness (mm)	Vickers Hardness(HV)
C2720	O	C2720.P-O	over0.3~under1	over 275	over 44	under 2	180	contact	over 0.3	-
			excess1~under30		over 50
		C2720.R-O	over0.3~under1		over 40
			excess1~under3		over 50
	1/4H	C2720.P-1/4H	over0.3~under30	325~410	over 35	under 2	180	thickness x 0.5	over 0.3	75~125
		C2720.R-1/4H	over0.3~under3
	1/2H	C2720.P-1/2H	over0.3~under20	355~440	over 28	under 2	180	thickness x 1	over 0.3	85~145
		C2720.R-1/2H	over0.3~under3
	H	C2720.P-H	over0.3~under10	over 410	-	under 2	180	thickness x 1.5	over 0.3	over 105
		C2720.R-H	over0.3~under3

Alloy No.	Temper condition	Code	Tensile Test			Bending Test			Hardness Test
			Thickness (mm)	Tensile Strength (N/mm²)	Extruding Rate(%)	Thickness (mm)	Bending Angle	Inner Radius	Thickness (mm)	Vickers Hardness(HV)
C2801	O	C2801.P-O	over0.3~under1	over 325	over 35	under 2	180	thickness x 1	-	-
			excess1~under30		over 40
		C2801.R-O	over0.3~under1		over 35
			excess1~under30		over 40
	1/4H	C2801.P-1/4H	over0.3~under30	355~440	over 25	under 2	180	thickness x 1.5	over 0.3	85~145
		C2801.R-1/4H	over0.3~under3
	1/2H	C2801.P-1/2H	over0.3~under20	410~490	over 15	under 2	180	thickness x 1.5	over 0.3	105~160
		C2801.R-1/2H	over0.3~under3
	H	C2801.P-H	over0.3~under10	over 470	-	under 2	180	thickness x 1	over 0.3	over 130
		C2801.R-H	over0.3~under3
